GigaEter Duo 19 5GHz WideBand
Broad-band double polarizated antenna with gain of 19 dBi
- broad-band double polarizated antenn
- Frequency range: 4,9 - 6,0 GHz
- Gain: 19 dBi
- Connector: 2xN/Female
- MIMO 2x2
Preț prea mare? Autentificați-vă și cumpărați mai ieftin
Plasați comanda până la ora 12:00, iar coletul va fi expediat în aceeași zi
Livrare gratuita de la 500 RON
Promocja cenowa na model HDR-15-5
GigaEter Duo 19 5GHz WideBand
Modele
-
Model Disponibilitate Garanție Lista de dorințe Prețul tăuPrețul tău Cantitate articole AdăugareGigaEter Duo 19 5GHz WideBand (3200)directional 5 GHz MIMO 19 dBiÎn stocGaranție: 245,00 RON301,35 RONIntră în cont pentru a vedea prețurile GigaEter Duo 19 5GHz WideBand (3200)directional 5 GHz MIMO 19 dBiDisponibilitate:În stocPreț net:245,00 RON
Descriere
PAN 5-19HV WB is broad-band double polarizated antenna with gain of 19 dBi, it's predicted for operation at the frequency of 4900 - 6000 MHz. Antenna is designed for
dual links and 2x2 MIMO links at the standard of 802.11n on medium distances.
Separation between connectors is 37dB. This antenna distinquish itself with wide beamwidth, from 4900 MHz up to 6000MHz. Medium antenna gain allows for realize wireless links on
medium distances. Narrow radiation beam allows to avoid interferences and noise level even on short distances.
Antenna has DC ground what prevents devices connected with antennas.
Solid bracket and U-Bolt come with antenna, they ensure for stability and resistance for wind and allows for antenna slope (advantage with making precise links).
Specificație tehnică
| Antenna type | directional |
| Frequency range | 4,9 - 6,0 GHz |
| Gain for vertical polarization | 19 dBi (min) 5,25-5,875 GHz 17.5dBi (min) 4,9-5,25 GHz; 5,875 - 6,0 GHz dBi |
| Gain for horizontal polarization | 19 dBi (min) 5,25 - 5,875 GHz 17.5dBi (min) 4,9 - 5,25 GHz; 5,875 - 6,0 GHz dBi |
| Polarization | vertical + horizontal |
| Back ratio | (max) -30 dB |
| Separation between connectors | > 37 dB |
| Vertical beam width | 18 ° for -3dB |
| Horizontal beam width | 18 ° for -3dB |
| VSWR | 1,5:1 (typ) 1,9 : 1 (max) |
| Impedance | 50 Ohm |
| Connector | 2 x N/Female |
| Maksymalna moc | 6 W |
| Wind load | 56 m/s |
| The diameter of the mast / pole | 38 - 51 mm |
| Dimensions | 390 x 430 mm |
| Package dimension | 49/41/9 cm |
| Total weight | 1654 g |
| Weight with mounting | 1250 g |
| Weight without mounting | 850 g |
| Warranty | 36 months |
