Producător: MEAN WELL
- input voltage range 3 ~ 14VDC
- high efficiency up to 90%
- output voltage adjustment
- short circuit protection
- remote on / off
- cooling in open air circulation
- working temperature -40 ~ + 82 ° C
- low cost, high reliability
- 3-year warranty
Discounted prices and exact stock levels are visible after logging in to the e-shop.
Preț de la 19,80 RON Net
Preț prea mare? Autentificați-vă și cumpărați mai ieftin
Produs epuizat
Livrare gratuita de la 500 RON
Promocja cenowa na model HDR-15-5
Produs destinat exclusiv utilizării profesionale
Modele
-
Model Disponibilitate Garanție Lista de dorințe Prețul tăuPrețul tău Cantitate articole AdăugareSPOL-01DC/DC converter 5.5W 3~14V/5V 1AOut of stock Garanție: 19,80 RON24,35 RONIntră în cont pentru a vedea prețurile SPOL-01DC/DC converter 5.5W 3~14V/5V 1ADisponibilitate: Out of stockPreț net:19,80 RON
Descriere
MEAN WELL SPOL-01 is a dc / dc converter in the form of a PCB module designed for soldering. Its characteristic features are small dimensions, high efficiency and the ability to remotely regulate the output voltage. High quality, reliability, durability and long service life are the basic advantages of MEAN WELL inverters.
Specificație tehnică
- SPOL-01: DC / DC converter, adjustable, PCB module type SPECIFICATION
| Model | Input | Output | Ripple&Noise | Efficiency | Dimensions |
| SPOL-01 | 3~14V | 5.5V, max.1A | 40mV | 90% | 12.4x12.4x4.0mm |
| 5V, max.1A | 40mV | 89.5% | 12.4x12.4x4.0mm | ||
| 3.3V, max.1A | 40mV | 86% | 12.4x12.4x4.0mm | ||
| 2.5V, max.1A | 40mV | 83% | 12.4x12.4x4.0mm | ||
| 1.8V, max.1A | 40mV | 79% | 12.4x12.4x4.0mm | ||
| 1.5V, max.1A | 40mV | 75% | 12.4x12.4x4.0mm | ||
| 1.2, max.1A | 40mV | 71% | 12.4x12.4x4.0mm | ||
| 0.9V, max.1A | 40mV | 67% | 12.4x12.4x4.0mm |
